| Product Glance |
Value |
| Model |
S21 XP Imm. |
| Crypto algorithm/coins |
SHA256 | BTC/BCH/BSV |
| Working mode(1-1) |
|
| Typical hashrate, TH/s(1-2) |
|
| Power on wall @30℃(1-3) , Watt(1-2) |
|
| Power efficiency on wall @30℃, J/TH(1-2) |
|
| Detailed Characteristics |
Value |
| Power Supply |
|
| Phase |
3 |
| Input voltage range, Volt(2-1) |
380~415 |
| Input frequency range, Hz |
50~60 |
| Input max current, Amp |
12 |
| Hardware configuration |
|
| Networking connection mode |
RJ45 Ethernet 10/100M |
| Server size (Length*Width*Height, w/o package), mm |
364(2-2)*236*293 |
| Server size (Length*Width*Height, with package), mm |
600*390*450 |
| Net weight, kg |
16.8 |
| Gross weight, kg |
18.5 |
| Environment requirements |
|
| Inlet oil temperature, °C |
20~50 |
| Oil flow, m3/h |
1 |
| Storage temperature,°C |
-20~70 |
Notes:
(1-1) NEM: Normal Energy Mode; HEM: High Energy Mode.
(1-2) The Hashrate value, Power on wall, and Power efficiency on wall are all typical value. The actual Hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%.
(1-3) Inlet oil temperature.
(2-1) Caution: Wrong input voltage may cause server damage.
(2-2) The height includes a 44mm handle.
