T21

Short Description:


Product Detail

Product Tags

| Specifications

Product Glance
Model T21
Version 10
Crypto algorithm/coins SHA256 | BTC/BCH/BSV
Working mode(1-1)
NEM HEM
Typical hashrate, TH/s(1-2)
190 233
Power on wall @30℃(1-3) , Watt(1-2)
3610 5126
Power efficiency on wall @30℃, J/TH(1-2)
19.0 22.0



Detailed Characteristics
Power supply
Phase 3
Input voltage(2-1), Volt 380~415
Input frequency range, Hz 50~60
Maximum input current, Amp 12
Hardware configuration
Network connection mode RJ45 Ethernet 10/100M
Server size (length*width*height, w/o package), mm 400*212*290
Server size (length*width*height, with package), mm 570*316*430
Net weight, kg 17.0
Gross weight, kg 19.1
Noise(2-2)@30°C, dBA 76
Environment requirements
Operation temperature, °C 0~45
Storage temperature, °C -20~70
Operation humidity(non-condensing), RH 10%~90%
Operation altitude(2-3), m ≤2000

NOTE:

(1-1) NEM: Normal Energy Mode; HEM: High Energy Mode.
(1-2) The Hashrate value, Power on wall, and Power efficiency on wall are all typical value. The actual Hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%.
(1-3) Inlet air temperature.
(2-1) Caution: Wrong input voltage may probably cause server damaged.
(2-2) The noise is loudest when the fan is under maximum RPM(rotation per minute).
(2-3) When the server is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m.
