S19 Pro

Short Description:


Product Detail

Product Tags

Product Description

Specifications:

Product Glance

Model

S19 Pro

Algorithm | Cryptocurrency

SHA256 | BTC/BCH/BSV

Hashrate, TH/s

110 ±3%

Power on wall @25°C, Watt

3250 ±5%

Power efficiency on wall @25°C, J/TH

29.5 ±5%



Detailed Characteristics

Power Supply
Power supply AC Input voltage, Volt(1-1)

200~240

Power supply AC Input Frequency Range, Hz

47~63

Power supply AC Input current, Amp(1-2)

20(1-3)

Hardware Configuration

Networking connection mode

RJ45 Ethernet 10/100M

Miner Size (Length*Width*Height, w/o package),mm(2-1)

370*195.5*290

Miner Size (Length*Width*Height, with package),mm

570*316*430

Net weight, kg(2-2)

13.2

Gross weight, kg

15.2

Environment Requirements
Operation temperature,°C

0~40

Storage temperature,°C

-20~70

Operation humidity(non-condensing) , RH

10~90%

Operation altitude, m(3-1)

≤2000

NOTE:

1.To prevent the spread of virus in the firmware, which can cause damage to the ANTMINER S19 series, the setting function of “Secure Boot” has been switched on and the “Root Authority” function has been disabled.

2.If the user fails to use the product in accordance with the given instructions, specifications, and conditions provided, or change the function setting without BITMAIN’s prior consent, BITMAIN will not be liable for any damage arising therefrom.

(1-1) Caution: Wrong input voltage may probably cause miner damaged

(1-2) Max condition: temperature 40°C, altitude 0m

(1-3) Two AC input wires, 10A per wire

(2-1) ​​​​Including PSU size

(2-2) Including PSU weight

(3-1) When the miner is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m
